SPN 520372 / SPN 520371 – Intake or Outlet NOx Sensor Fault (Full 2025 Fix Guide)

SPN 520372 / SPN 520371 – Intake or Outlet NOx Sensor Fault (Full 2025 Fix Guide)

If your truck is showing:

  • SPN 520372 FMI 2/3/4/16/18 — Intake NOx Sensor Fault

  • SPN 520371 FMI 2/3/4/16/18 — Outlet NOx Sensor Fault

…you’re dealing with MAJOR aftertreatment failures that will lead to:

  • Failed regens

  • DEF doser shutdown

  • “DEF Quality Poor”

  • P20EE / P207F

  • SPN 4364 (SCR Efficiency Low)

  • 5 MPH Derate (SPN 5246)

NOx sensor faults are the #1 cause of SCR derates on nearly ALL modern diesel engines.

🚨 What Do SPN 520372 & SPN 520371 Mean?

These codes indicate:

  • The NOx sensor heater failed

  • The sensor is not responding

  • The NOx values are stuck

  • The voltage is out of range

  • The sensor is reading incorrect NOx levels

  • Sensor is reporting impossible values

SPN 520372 = Intake NOx Sensor Fault

Measures NOx coming out of the engine BEFORE the SCR.

SPN 520371 = Outlet NOx Sensor Fault

Measures NOx AFTER the SCR to determine efficiency.

If either of these sensors fail → SCR system shuts down.

⚠️ Symptoms of SPN 520372 / 520371

  • Check engine light

  • DEF light

  • SCR fault

  • “DEF Quality Poor”

  • Frequent regens

  • Regen won’t complete

  • Loss of power

  • Black smoke

  • “Engine Will Derate”

  • SPN 5246 (DERATE)

  • SPN 4364 (SCR Efficiency Low)

If your NOx sensors aren’t working, the ECM CANNOT protect the emissions system — so it derates you.

🔍 Real Causes of SPN 520372 / 520371 (Ranked)

1. Failed NOx Sensor (MOST COMMON – 80% of cases)

NOx sensors fail constantly due to:

  • Heat cycles

  • Thermal shock

  • Corrosion

  • Internal heater failure

  • Contaminated exhaust

  • Electrical degradation

If readings are stuck or unrealistic → sensor is bad.

2. Sensor Heater Failure

Each NOx sensor contains a heated ceramic cell.

If heater fails:

  • Sensor cannot reach operating temp

  • ECM throws SPN 520372/520371 immediately

  • SCR checks fail

3. Wiring Problems

Especially common on:

  • Cummins X15/ISX

  • Detroit DD15

  • Paccar MX-13

Look for:

  • Green corrosion

  • Broken locking tabs

  • Water intrusion

  • Damaged harness insulation

4. Exhaust Leaks

Upstream leaks allow fresh air into exhaust → incorrect NOx readings.

5. DEF System Issues (Secondary)

If DEF dosing is incorrect:

  • NOx outlet stays high

  • Outlet sensor seems “faulty”

  • P20EE or P207F appears

6. SCR Catalyst Efficiency Problems

If NOx outlet stays high AFTER DEF injection → ECM blames the outlet sensor.

However: Outlet sensor is far more likely to fail than the SCR.

❌ What NOT To Do

❌ Don’t clear the code and keep driving

Derate WILL occur.

❌ Don’t replace the SCR first

SCR catalyst is almost never the problem.

❌ Don’t rely on a cheap OBD reader

You MUST see NOx ppm and sensor voltage.

❌ Don’t replace both sensors blindly

You should verify with diagnostics.

🛠️ How to Fix SPN 520372 / 520371 (Dealer-Level Diagnostic Procedure)

To diagnose correctly, you MUST use:

  • JPRO

  • Diesel Tech

  • Cummins Insite

  • Detroit DDDL

  • Paccar Davie

  • Volvo Tech Tool

These tools allow:

  • NOx sensor testing

  • Heater activation test

  • Efficiency graphs

  • SCR reset

  • DEF system testing

  • Forced regens

⭐ STEP 1 — Check Inlet vs Outlet NOx Readings

Normal working system:

👉 Outlet NOx should be 70–95% lower than inlet.

If outlet = inlet → outlet NOx sensor failed.

If inlet is unrealistically high → inlet NOx sensor is bad.

⭐ STEP 2 — Perform the NOx Heater Test

The heater is the most common failure.

Software will instantly confirm if it’s dead.

⭐ STEP 3 — Check Sensor Voltage

If voltage is:

  • Flat

  • Zero

  • Over 5V

  • Not changing with load

→ Sensor is failed.

⭐ STEP 4 — Inspect Wiring & Connector Pins

Look for:

  • Corrosion

  • Loose connectors

  • Pin push-out

  • Moisture

  • Melted wires

⭐ STEP 5 — Check Exhaust Leaks

Leaks around:

  • Flex pipe

  • DPF outlet

  • SCR inlet

  • Turbo flange

…cause false NOx readings.

⭐ STEP 6 — Replace Sensor (If Needed)

Use OEM ONLY:

  • Cummins

  • Detroit

  • Paccar

  • Volvo

  • Bosch (OEM supplier)

Cheap aftermarket NOx sensors FAIL quickly.

⭐ STEP 7 — Run SCR & NOx Sensor Resets

These resets are REQUIRED:

  • NOx inlet reset

  • NOx outlet reset

  • SCR efficiency reset

  • DEF dosing reset

  • Aftertreatment learned data reset

If ANY reset is skipped → codes return.

⭐ STEP 8 — Perform a Forced Regen

A regen:

  • Stabilizes NOx readings

  • Validates SCR function

  • Verifies temperatures

  • Clears derate logic

💻 Tools You Need to Fix SPN 520372 / 520371

You MUST have:

✔ Diesel diagnostic laptop

✔ Nexiq USB-Link 3

✔ NOx sensor test functions

✔ DEF/SCR reset capability

✔ Forced regen controls

DieselScanners kits include:

  • Inlet/outlet NOx live data

  • SCR efficiency tests

  • DEF pump/doser tests

  • NOx resets

  • Aftertreatment resets

  • Unlimited regens

  • Lifetime support

📞 Need help choosing the right tool? Call: (800) 987-4850

💲 Why Misdiagnosing NOx Sensors Is Expensive

Shops often replace:

❌ SCR catalyst ($2,000–$6,000)
❌ DEF pump ($900–$1,800)
❌ Doser ($300–$600)
❌ Injectors ($2,000+)
❌ Wiring harness ($800–$1,500)

When the real issue was:

  • A $250 NOx sensor

  • A wiring fix

  • A regen

Your diagnostic kit:

👉 Shows EXACT ppm
👉 Verifies heater function
👉 Performs resets
👉 Saves thousands

🚛 Fix SPN 520372 / 520371 Before Derate Hits

If ignored:

  • SCR shuts down

  • DEF dosing stops

  • P20EE appears

  • SPN 5246 triggers

  • Full 5 MPH DERATE

Fix it today with DieselScanners.
